Provision 4Channel NVR
Provision-ISR NVR5-4100X+(MM) is an easy-to-install solution suitable for small-sized installations (up to 4 channels). The device, available in the elegant mini metal case, provides you with everything you need for a trouble-free CCTV project.
Product Description
Provision-ISR NVR5-8200X+(MM) is an easy-to-install solution suitable for small-sized installations (up to 8 channels) The device, available in the elegant mini metal case, provides you with everything you need for a trouble-free CCTV project.
Kit Includes
- Standalone 4channel NVR, H.265
- Support: VMS
- DDA Analytics & LPR
- 1xSATA – 6TB (not included)
- No PoE
Features
Video:
- Input: 4 Channel Support
- 4 Channel Standard Connection (Via RJ-45 Network Port)
- Output: HDMI / VGA (1080P, 1280×1024, 1024×768)
Bandwidth:
- Incoming: 32Mbps
- Outgoing: 32Mbps
- Decoding Support: H.265S/H.265+/H.265/H264
Analytics:
- Camera Tampering, DDA2 With Object Classification, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Object Monitoring, Object Counting (DDA), Crowd Gathering, Smart Search, LPR, Loitering Detection, Illegal Parking, Audio Exception
- *DDA/LPR Analytics Live Snapshots are not supported
Recording:
- 4CH 5MP Real-Time
- FPS: 100 (PAL) / 120 (NTSC)
Playback:
- Local: 4Ch Simultaneously
- Remote: 4Ch Simultaneously
Audio:
- Input: IPC Inputs Only
- Output: IPC Outputs Only
Alarm:
- Input: Based on IPC Only
- Output: Based on IPC Only
Storage:
- 1 x SATA (Up to 6TB each)
USB Port:
- 2 USB 2.0 Port
Network:
- 1 x RJ-45: 10/100Mbps Each
Remarks:
- The following features are based on firmware v1.4.10_70351 and are subject to firmware version changes.
